SINGLE FIBER WELDING HEAD
Product Description:
Suitable for welding on medium and thick plate materials.
Can be used with power feedback compensation module and welding monitoring modules.
PRODUCT HIGHLIGHTS
The internal structure of the welding head is completely sealed, which prevents the optical part from being contaminated by dust
Lens set indirect water cooling, reliable performance, can work stably for a long time, prolong service life
Equipped with coaxial blowout components to reduce welding fume and spatter residue contamination of the lens
With coaxial visual monitoring system, built-in blue coaxial light source
Modular design, protective lenses with drawer structure, easy to replace
SPECIFICATIONS
| Laser Wavelength | 1070nm |
| Maximum Power | 6000W |
| Collimation | 100mm, 125mm, 150mm |
| Focusing | 150mm, 200mm, 250mm |
| Cooling | Water |
| WPD | Selectable |
| Visual | Selectable |
| Size | 493×130×98mm |
| Weights | 2.8kg |
