Description
Application
·Telecommunication System
·Testing Facility
·CATV, LANs, WANs
·QSFP Module
·Data center system networks
Compliance
·Compliant with : IEC-61754-20
·Compliant with : Tecordia-GR-326-CORE
·Compliant with : RoHS
| Parameters | ||||
| Fiber Mode | SM
(G652D/G657A1/G657A2) |
MM
(OM1/OM2/OM3/OM4) |
||
| Connector Type | SC | |||
| Diameter (mm) | Φ 0.9、Φ 1.6、Φ 2.0、Φ 3.0… | |||
| End-face Finishing | PC | UPC | APC | PC |
| Standard Insertion Loss (dB) | ≤0.75(max)
≤0.35(typical) |
≤0.60(max)
≤0.35(typical) |
||
| Low Insertion Loss (dB) | ≤0.35(max)
≤0.20(typical) |
≤0.35(max)
≤0.20(typical) |
||
| Return Loss (dB) | ≥45 | ≥50 | ≥60 | ≥20 |
| Connector (optional) | Male / Female | |||
| Exchangeability (dB) | ≤0.20 | |||
| Repeatability (dB) | ≤0.20 | |||
| Operating Temperature(℃) | -25 ~ +70 | |||
| Storage Temperature (℃) | -40 ~ +85 | |||
| Operating Wavelength(um) | 1310, 1550 | 850 | ||
