Fiber Optic Closure

Category:
Fiber Optic Closure

Availability: In Stock

Features

1.Cable diameter: 1 uncut port meet φ8～18mm cable; 4 branch ports meet φ8～18mm cable

2.Product capacity: Single fiber max capacity is up to 144F, also support max 432F ribbon fiber

3.Installation method: Suitable for direct buried, aerial, pole, pipeline, manhole, etc

4.Sealing mode: mechanical seal is adopted for cable ports, with protection grade of IP68

5.Splice tray can accommodate mini PLC if required. It can also accommodate micro cable with grommet

Category:

Description

fiber optic closure is designed for connection and protection of fiber cables.This model has one uncut port, four branch ports. It can be used for different applications of optical fiber cable splicing & branching and is suitable for aerial, pipe-lined, manhole and direct buried applications. It applies to any sort of cables (loose tube, skeleton, ribbon etc.)



Parameters
Model No. JFOC-5601
Style Dome
Dimensions(mm) 455×Φ225
Weight (kg) 3.5 – 4.5
Material PP+GF
Sealing Type Mechanical Seal
Protection Grade IP68
Cable ports Oval port 1 Φ8 – Φ18 mm
Branch port 4 Φ8 – Φ18 mm
Closure Max Capacity Single fiber splicing 144F
Ribbon fiber splicing 432F/576F
Max No. tray installed 6pc
PLC Splitter 1pc splitter
Installation Aerial, wall, pole, manhole etc.
