GR SERIES
GR 200-300W
GR 200-300W
The JPT GR series laser adopts a Master Oscillator Power Amplifier (MOPA) configuration, supporting independent adjustment of pulse width and pulse frequency. Building upon the flexible parameter control of MOPA lasers, it incorporates external cavity frequency doubling technology to deliver high-power green laser output. This system is particularly suitable for: Copper welding applications, Photovoltaic processing, Precision marking.
300W Maximum average power
532nm Center emission wavelength
10-250ns Adjustable pulse width
ADVANTAGES
Adjustable pulse width & frequency
High pulse energy
High beam quality
Water-cooled design for enhanced stability
APPLICATIONS
SPECIFICATIONS
Parameter | Unit | YDFLP-GR-200 | YDFLP-GR-300 |
|---|---|---|---|
| Product Model | YDFLP-GR-200 | YDFLP-GR-300 | |
| M² | <1.6 | <1.6 | |
| Armored Cable Length | m | 3 | 3 |
| Nominal Average Output Power | W | 200 | 300 |
| Maximum Pulse Energy | µJ | 200 | 200 |
| Pulse Repetition Rate Range | kHz | 1~4000 | 1~4000 |
| Pulse Width | ns | 1.5×1-3burst or 10-250 | 1.5×1-3burst or 10-250 |
| Output Power Instability | % | <5 | <5 |
| Cooling Method | Water Cooled | Water Cooled | |
| Operating Voltage | V | 220 (AC) | 220 (AC) |
| Nominal Power Consumption | W | 1200 | 2000 |
| Supply Power Demand | W | ≥1400 | ≥2200 |
| Central Emission Wavelength | nm | 532 | 532 |
| Emission Bandwidth @3dB | nm | <2 | <2 |
| Output Power Tuning Range | % | 0~100 | 0~100 |
| Operating Temperature | °C | 10~40 | 10~40 |
| Host Machine Weight | kg | 40 | 40 |
| Output Head Weight | kg | 10 | 10 |
| Host Machine Dimensions (L×W×H) | mm | 599×440×108 | 599×440×108 |
| Output Head Dimensions (L×W×H) | mm | 370×260×52 | 370×260×52 |
