Dome Fiber Optic Closure JFOC09-5802
Dome Fiber Optic Closure JFOC09-5802
JFOC09-5802 type of fiber optic closure is designed for connection and protection of fiber cables.This model has one uncut port, four branch ports. It can be used for different applications of optical fiber cable splicing & branching and is suitable for aerial, pipe-lined, manhole and direct buried applications.
- IP68 Protection Grade
- 432 Max Cores Capacity
PRODUCT FEATURES
° Mechanical seal for the box and cable ports, with good sealing performance, easy for operation
° Protection grade: IP68
° Splice trays are all tightly fixed by black buckle when splicing
° Applicable for both bundle cable and ribbon cable
° Installation method: wall mounting, pole mounting, direct buried, etc
PRODUCT APPLICATIONS
SPECIFICATIONS
Product Model | JFOC09-5802 |
| Size | 455×Φ225 mm |
| Material | PP+GF |
| Splice Tray | 6 tray |
| Max. Capacity | Bundle cable: 144F Ribbon cable: 432F |
| Cable Port | 1 oval port + 4 round port |
